Measuring, visualization and transmission of electrical measuring values within low voltage installations (max. 500 V L-L, 289 V L/N). Use in 1phase as well as 3phase grids. Typical applications: industry, e. g. Food&Beverage, Chemistry, Pharma etc.
Measuring voltage, frequency, current, power, as well as imported and exported active and reactive power.
Number of applications
Loop power supply
100 - 400 V AC
AC 110 - 400 V +/- 10% (110 - 300 V for installations acc. to UL) DC 120 - 350 V +/-20% (120 - 300 V for installations acc. to UL)
MODBUS RTU (RS485) Pulse output
71.3 x 90.5 x 58 mm (2.81" x 3.56" x 2.28")
4 button on site at the front side of the multifuntional measuring device
triple-spaced background illuminated LCD-display
Measured process variables: Current (A), voltage (V), calculated neutral current (A), frequency (Hz) in low-voltage systems Calculated process variables: Power factor (PF = cos phi), real power (W), reactive power (VAR) Apparent power (VA), imported and exported active (kWh) - and reactive energy (kvarh) and total harmonic distortion (THD)
