OPC DA Server, RXO20
Standard for exchange of measuring data

OPC Server, standardized data exchange ©Endress+Hauser

Download:
OPC Server Software

Visualization and monitoring of processes

The OPC DA server enables access to process data e.g. instantaneous values or totalizers from the connected Endress+Hauser field devices. The OPC server provides the data to OPC clients in real time. With an OPC client software the process data can be visualized. Communication is made either by using an RS232/RS485 interface or a TCP/IP connection. OPC is applied in areas of factory and process automation independent of their size.

Seleção rápida

Escolha uma das opções sugeridas
    -- selected coding
    -- selected label
    <%label%>
    -- selected coding
    -- selected label
    <%feature%>
  • Process Connection
      <%label%>
      <%label%>

  • <%message%>

RXO20
Exibir detalhes Ocultar detalhes
Exibir detalhes
Voltar à seleção rápida
  • <%feature%>
    <%coding%>
    <%label%>
pc
  • Acessórios opcionais
Use o configurador individual para continuar.
ou

Configuração individual

Continue sua seleção entre todas as opções possíveis

  • Benefícios

    • Easy connection to process visualization systems via standard interface OPC

    • Low integration costs

    • Simple handling on plant expansions

    • Fulfils the OPC DA Data Access Specification

    • Possible to connect multiple OPC clients

  • Campo de aplicação

    The OPC Server can communicate with the following devices:

    • Ecograph A, Ecograph T

    • Memograph, Memograph S, Memograph M

    • Alphalog

    • RMS621, RMC621, RMM621

    • FML621

    • RA33, EngyCal RH33, EngyCal RS33

Características e especificações

Voltar

Details

  • Measuring principle

    Additional expertise

  • Application Task

    Data acquisition

  • Field of Application

    The OPC DA Server allows data access to instantaneous values from different Endress+Hauser devices. These data are made available to OPC clients in real time.

    Communication is made either by using an RS232/RS485 interface or a TCP/IP connection.

    The OPC server supports

    the Ecograph

    the Memograph

    the Energy manager family

    the batch controller.

  • Operating systems

    Microsoft Windows 2000 SP4

    Microsoft XP SP2 (32 Bit)

    Microsoft Windows Server 2003

    Windows 2008 Server (32/64 Bit)

    Microsoft Vista (32 Bit)

    Windows 7 (32/64 Bit)

  • Processor type

    Pentium 200 MHz (≥400 MHz recommended)

  • Main memory

    At least 128 MB

  • Hard-disk capacity

    Disk space needed:
    At least 100 MB

  • Registered Trademarks

    Microsoft

    Windows

    Windows XP

    Windows 8 and the Microsoft logo are registered trademarks of the Microsoft Corporation.

    All other brand and product names are trademarks or registered trademarks of the companies and organisations in question.

  • Measuring principle

    Electronic Data Acquisition

  • Software package

    System requirements:

    Operating system: Windows® 2000, Windows® XP, Windows Vista™, Windows Server® 2003/2008, Windows 7™

    Processor: 200 MHz min.; 400 MHz or higher is recommended

    RAM: 128 MB or more
